"U" or "Z" Shaped Conveyor Cross Over Unit


CU CZ Series
Specifications:
  • 45 degree angle of climb - 9" rise, 9" run
  • Four piece construction for easy installation
  • 1 1/2" diameter tubular steel frame
  • 9 1/2" deep x 24" wide diamond plate steps
  • 24" wide diamond plate deck
  • 4" toeboard on both sides
  • 27" overall width
  • Stair supports on longs span units
  • Yellow enamel painted finish

Options:
  • Bridge inserts for additional horizontal clearance
  • Custom widths and vertical clearances
  • Safety grating steps and decks
  • Closed risers
  • Center towers for multiple spans
  • Custom entry and exit configurations
  • Optional painted finishes
  • Hot dip galvanized finish

Click here to e-mail us for more information or call us at our Toll-Free number (800) 360-6789

MODEL   CONVEYOR CLERANCES VERTICAL HORIZONTAL DECK
HEIGHT 		PLATFORM
LENGTH 		STAIRSIDE
LENGTH 		WEIGHT
CU-3120
CU-3130
CU-3139
CU-3149
CU-4020
CU-4030
CU-4039
CU-4049
CU-4920
CU-4930
CU-4939
CU-4949
CU-5820
CU-5830
CU-5839
CU-5849
CU-6720
CU-6730
CU-6739
CU-6749
31"                 20"
31"                 30"
31"                 39"
31"                 49"
40"                 20"
40"                 30"
40"                 39"
40"                 49"
49"                 20"
49"                 30"
49"                 39"
49"                 49"
58"                 20"
58"                 30"
58"                 39"
58"                 49"
67"                 20"
67"                 30"
67"                 39"
67"                 49"
 36"
36"
36"
36"
45"
45"
45"
45"
54"
54"
54"
54"
63"
63"
63"
63"
72"
72"
72"
72"
73"
83"
92"
102"
73"
83"
92"
102"
73"
83"
92"
102"
73"
83"
92"
102"
73"
83"
92"
102"
54"
54"
54"
54"
63"
63"
63"
63"
72"
72"
72"
72"
81"
81"
81"
81"
90"
90"
90"
90"
 339 lbs.
359 lbs.
379 lbs.
399 lbs.
376 lbs.
396 lbs.
416 lbs.
436 lbs.
413 lbs.
433 lbs.
453 lbs.
473 lbs.
450 lbs.
470 lbs.
490 lbs.
510 lbs.
487 lbs.
507 lbs.
527 lbs.
547 lbs.
